8” SLIM PROFESSIONAL LOUDSPEAKER HYBRID WITH CARBON FIBER WATER RESISTANT AND 1” COMPRESSION DRIVER HORN

Experience unparalleled acoustic performance with the Genius Audio MRH8.2CP. This 8-inch professional hybrid loudspeaker integrates a powerful midrange driver with an integrated 1-inch compression driver horn, delivering a full and articulate frequency range from 130Hz to 20KHz. Engineered for extreme environments, the MRH8.2CP features a robust, water-resistant carbon fiber cone and a high-sensitivity design, providing 350 Watts RMS of clean, high-output sound in a slim profile.

Key Technical Specifications:

          Nominal Diameter: 8" (203 mm)

• Nominal Impedance: 4 Ohms
• Power Handling (RMS/MAX/PEAK): 350 Watts RMS / 700 Watts MAX / 1400 Watts PEAK
• Sensitivity (1w/1m): 95 dB
• Frequency Response: 130Hz - 20KHz
• Voice Coil Diameter: 1.5" (38.1 mm)
• Voice Coil Wire: CCAW (Copper-Clad Aluminum Wire)
• Voice Coil Former Material: Kapton®
• Magnet Material: Ferrite Y30
• Magnet Weight: 21 Oz.
• Mounting Depth: 81.8 mm / 3.22 in
• Front Mount Baffle Cutout: 183 mm / 7.2 in

Technical Features & Qualities:

• High Power Hybrid Design: Combines a mid-range driver and a 1" Compression Driver Horn, delivering a single-point source for a wide, smooth frequency response and high output.
• Superior Power Handling: Handles 350 Watts RMS, ensuring powerful, sustained, and distortion-free audio performance.
• Exceptional Efficiency (95 dB): High sensitivity maximizes acoustic output, achieving impressive volume with less amplifier power.
• Water-Resistant Carbon Fiber Cone: Provides extreme rigidity, lightweight performance, and superior durability, making it ideal for marine or off-road applications.
• Slim Mounting Profile: The shallow mounting depth (3.22 inches) facilitates installation in various space-constrained factory and custom locations.
• Durable Voice Coil Assembly: Features a 1.5" CCAW wire voice coil on a high-temperature Kapton® former for thermal stability and long-term reliability.
• Robust Motor Structure: Built with a high-strength 21 Oz. Ferrite Y30 magnet and a black-painted steel basket for maximum stability and endurance.
• Optimized Crossover Point: Recommended High Pass Crossover of 165Hz (12dB/Oct.) ensures perfect integration with dedicated subwoofers.
