6.5” OCTAGONAL MIDRANGE LOUDSPEAKER 700 W MAX

Engineered for enthusiasts seeking high performance and superior sound fidelity, the MRX65 is a 6.5-inch midrange loudspeaker designed to deliver exceptional vocal clarity and instrument punch. Built with a robust cast aluminum basket and a powerful Ferrite Y30 magnet, this speaker ensures durability and dynamic output, making it the perfect upgrade for any serious car audio system.

Technical Specifications:

• Nominal Diameter: 6.5" (165 mm) Octagonal design.
  • Benefit: Optimal size for easy installation in most vehicle door panels.
• Power Handling: 350 Watts RMS / 700 Watts MAX / 1400 Watts Peak.
  • Benefit: High power capacity allows for loud, sustained performance with reliability.
• Voice Coil: 2" (50.8 mm) diameter, CCAW wire on a Kapton® former.
  • Benefit: High-temperature design improves efficiency and handles significant power for extended periods.
• Nominal Impedance: 4 Ohm.
  • Benefit: Standard impedance ensures easy and effective pairing with most car audio amplifiers.
• Sensitivity (1w/1m): 92.4 dB.
  • Benefit: High sensitivity means the speaker converts amplifier power into loud sound efficiently, providing strong volume even with moderate power input.
• Frequency Response: 126Hz - 10.5KHz.
  • Benefit: Optimized frequency range for precise and clear reproduction of critical midrange frequencies (vocals and instruments).
• Magnet Material: Ferrite Y30 with a weight of 34 Oz.
  • Benefit: Strong magnetic field ensures excellent cone control, leading to precise sound dynamics and high efficiency.
• Cone/Surround Material: Paper Cone and Cloth Surround.
  • Benefit: Lightweight materials ensure quick response and accurate sound, while the cloth surround offers controlled excursion and durability.
• Basket Material: Cast Aluminum.
  • Benefit: Rigid construction minimizes structural resonance and vibration, resulting in cleaner, distortion-free sound.
• Mounting Depth: 3.35 in (85.2 mm).
  • Benefit: Relatively shallow depth simplifies installation in various custom and factory locations.
• Recommended High Pass Crossover: 170Hz (12dB/Oct.).
  • Benefit: Protects the speaker by filtering out harmful, low-frequency bass notes, maximizing performance and lifespan.
• Thiele-Small Parameters (Fs: 113 Hz, Qts: 0.493):
  • Benefit: Indicates the speaker is well-suited for a variety of enclosure designs, allowing audio installers to tune the box for optimal sound.
